Gigabyte outs three LGA1700 compatible MicroATX motherboards

Gigabyte has released three MicroATX motherboards that are LGA1700 compliant. In early April, they will be available for purchase.

A new DDR4 H610M S2 model has been discovered, and it is an Intel H610 chipset variation with only D-Sub display output. This is the lowest “H610M S2 DDR4” model that has been revealed so far. There are six phases and one additional phase in the power supply circuit, which uses 50A Low RDS (on) MOSFETs. The memory is DDR4-3200 x two (up to 64GB), the storage is SATA3.0 (6Gbps) x four, the M.2 x one, and the expansion slot is PCI-Express4.0 (x16) x one, and the expansion slot is PCI-Express3.0 (x1) x one. The network is equipped with a Realtek Gigabit LAN chip, and the board itself is 230x215mm in dimension.

HDMI support is included in the DDR4 H610M H (Intel H610M H) chipset type, which is an upgrade from the “H610M S2 DDR4”. The power supply circuit is a 6 + 1 + 1 phase arrangement with a 50A Low RDS (on) MOSFET, the memory is DDR4-3200 x 2 (maximum 64GB), the storage is SATA3.0 (6Gbps) x4, the extension slot is PCI-Express4.0 (x16) x1, and the expansion slot is PCI-Express3.0 (x1) x1. The motherboard has a PCI-Express4.0 (x16) expansion slot The network is equipped with a Realtek Gigabit LAN chip, and the board itself is 230x215mm in dimension.

It is equipped with an Intel B660 chipset and an Intel AC3168 wireless LAN module. It is a MicroATX motherboard with a DDR4 memory capacity of up to 32 GB. There are six phases and one zero phase in the power supply circuit, which uses 50A Low RDS (on) MOSFETs. The memory is DDR4-5333 x two (up to 64GB), the storage is SATA3.0 (6Gbps) x four, the M.2 x two, and the expansion slots are PCI-Express4.0 (x16) x one and PCI-Express3.0 (x1) x one. This network is wired and is comprised of one Realtek chip that provides 2.5 gigabits of LAN speed and measures 244x225mm in size.
